Belt Scale Weigh Feeder Controller Zero Calibration And Auto Zero Tracking

Brand Name : Supmeter

Model Number : BST100-B11

Certification : CE

Place of Origin : China

MOQ : 1pc

Price : negotiation

Payment Terms : Western Union, T/T

Supply Ability : 10000pcs/month

Delivery Time : 3workdays

Packaging Details : one pc per carton

Power supply : AC220V

DO : 4

Accuracy Grade : 0.5

DI : 3

Communication Port : COM1:Optional RS232/RS485/RS422/ Profibu-DP/Ethernet; COM2:RS485

Contact Now

Zero Calibration And Auto Zero Tracking Belt Scale Weighfeeder Controller

Technical Specification

  • Power Supply: AC220V±15%, 50/60Hz, Max. 15W.
  • Loadcell Excitation Voltage/Current: DC10V/250mA.
  • 8 Loadcells[350Ω] connectable.
  • Weighing Signal Input Range: 0~25mV.
  • Speed Sensor Excitation Voltage/Current: DC12V/100mA.
  • Speed Signal Input Range: 0.5~3000Hz.
  • 3 Normally Open Switch Inputs [DI].
  • 4 Normally Open Relay Outputs [DO]: AC250V/DC24V, 1A.
  • 1 ‘Totalized Weight’ Pulse Output [PO]: DC5~24V, 100mA.
  • 2 ‘PID Control’ Analog Output [AO]: 4~20mA, 0.05%FS.
  • 1 ‘Flow Set’ Analog Input [AI]: 4~20mA, 0.05%FS.
  • COM1: Optional RS232/RS485/RS422/Profibus-DP/Ethernet.
  • COM2: RS232.
  • Connect Host IPC, Remote Display, Printer&Wireless Module.
  • Outline Size [W×H×D]: 164 × 82 × 188 mm.
  • Panel Cut-out Size [W×H]: 153 × 77 mm.
  • Operating Temperature: -25℃～+45℃.
  • Protection Level of Front Panel: IP65.
  • Accuracy Grade: 0.5.
  • Accuracy of Flow Control: 0.5%~1.0%.

Appendix A. Print Formats

Belt Scale Weigh Feeder Controller Zero Calibration And Auto Zero Tracking

Belt Scale Weigh Feeder Controller Zero Calibration And Auto Zero Tracking

Model Panel-mounting Installation

Belt Scale Weigh Feeder Controller Zero Calibration And Auto Zero Tracking

Model Panel-mounting Terminal

Belt Scale Weigh Feeder Controller Zero Calibration And Auto Zero Tracking

Ration Flow Auto-Feeding System:

Belt Scale Weigh Feeder Controller Zero Calibration And Auto Zero Tracking

Display Interfaces

The Numeric Display 1 displays Totalized Weight value and the Numeric Display 2-3 displays the following data:

NO. Display iterms Sign Range
6 Totalized Weight of Current Batch P= 0~999999
7 AD Value Ad= 0~65535
8 Zero Value Zr= 0~60000
9~11 DI State dI1-/dI2-/dI3- -oFF/-on-
12~15 DO State do1-/do2-/do3-/do4- -oFF/-on-
16 AI Signal AI1= 4.00~20.00mA
17~19 AO Signal Ao1=/Ao2=/Ao3= 4.00~20.00mA
20 Totalized Weight High Speed Pulse HP 0~999999 Pulse
21 Totalized Weight Low Speed Pulse LP 0~999999 Pulse
22 Date 20YY.MM.DD Year. Month. Day
23 Time HH.MM.SS-W Hour. Minute. Second-Week
24 Totalized Weight of Current Shift t= 0~99999.9t
